1.
INTRODUCTION
=======================================
Are
you trying to learn c socket programming? Or do you think that it's hard stuff?
Well,
then you must read this basic tutorial to get basic ideas and concepts and to
start
to
work with sockets. Don't expect to be a "socket programming master"
after reading this
tutorial.
You'll only be that if you practice and read a lot.
2.
DIFFERENT TYPES OF INTERNET SOCKETS
=======================================
In
the first place I must explain what a socket is. In a very simple way, a socket
is a way
to
talk to other computer. To be more precise, it's a way to talk to other
computers using
standard
Unix file descriptors. In Unix, every I/O actions are done by writing or
reading
to
a file descriptor. A file descriptor is just an integer associated with an open
file and it
can
be a network connection, a terminal, or something else.
About
the different types of internet sockets, there are many types but I'll just
describe two
of
them - Stream Sockets (SOCK_STREAM) and Datagram Sockets (SOCK_DGRAM).
"And
what are the differences between this two types?" you may ask. Here's the
answer:
Stream Sockets - they're error free; if you send through the stream socket
three
items "A,B,C", they will arrive in the same order -
"A,B,C" ;
they use TCP ("Transmission Control Protocol") - this protocol
assures the items' order.
Datagram Sockets - they use UDP ("User Datagram Protocol"); they're
connectionless
because you don't need to have an open connection as in Stream
Sockets - you build a packet with the destination information and
send it out.
A
lot more could be explained here about this two kind of sockets, but I think
this is enough
to
get the basic concept of socket. Understanding what a socket is and this two
types of
internet
sockets is a good start, but you need to learn how to "work" with
them. You'll learn
it
in the next sections.
3.
STRUCTURES
=======================================
The
purpose of this section is not to teach you structures but to tell you how are
they
used
in C socket programming. If you don't know what a structure is, my advice is to
read
a
C Tutorial and learn it. For the moment, let's just say that a structure is a
data type
that
is an aggregate, that is, it contains other data types, which are grouped
together into
a
single user-defined type.
Structures
are used in socket programming to hold information about the address.
The
first structure is struct sockaddr that holds socket information.
struct sockaddr{
unsigned short sa_family; /* address family */
char sa_data[14];
/* 14 bytes of protocol address */
};
But,
there's another structure (struct sockaddr_in) that help you to reference to
the socket's
elements.
struct sockaddr_in {
short int
sin_family; /* Address family */
unsigned short int sin_port; /* Port */
struct in_addr
sin_addr;
/* Internet Address */
unsigned char
sin_zero[8]; /* Same size as struct sockaddr */
};
Note:
sin_zero is set to all zeros with memset() or bzero() (See examples bellow).
The
next structure is not very used but it is defined as an union.
As
you can see in both examples bellow (Stream Client and Server Client) , when I
declare for
example
"client" to be of type sockaddr_in then I do client.sin_addr = (...)
Here's
the structure anyway:
struct in_addr {
unsigned long s_addr;
};
Finally,
I think it's better talk about struct hostent. In the Stream Client Example,
you can
see
that I use this structure. This structure is used to get remote host
information.
Here
it is:
struct hostent
{
char
*h_name;
/* Official name of host. */
char
**h_aliases;
/* Alias list. */
int
h_addrtype;
/* Host address type. */
int
h_length;
/* Length of address. */
char
**h_addr_list; /*
List of addresses from name server. */
#define h_addr h_addr_list[0] /* Address, for backward
compatibility. */
};
This
structure is defined in header file netdb.h.
In
the beginning, this structures will confuse you a lot, but after you start to
write some
lines,
and after seeing the examples, it will be easier for you understanding them. To
see
how
you can use them check the examples (section 8 and 9).
4.
CONVERSIONS
=======================================
There
are two types of byte ordering: most significant byte and least significant
byte.
This
former is called "Network Byte Order" and some machines store their
numbers internally
in
Network Byte Order.
There
are two types you can convert: short and long.
Imagine
you want to convert a long from Host Byte Order to Network Byte Order. What
would you
do?
There's a function called htonl() that would convert it =) The following
functions are
used
to convert :
htons() -> "Host to Network Short"
htonl() -> "Host to
Network Long"
ntohs() -> "Network
to Host Short"
ntohl() -> "Network to Host Long"
You
must be thinking why do you need this. Well, when you finish reading this
document, it will
all
seems easier =) All you need is to read and a lot of practice =)
An
important thing, is that sin_addr and sin_port (from struct sockaddr_in) must
be in Network
Byte
Order (you'll see in the examples the functions described here to convert and
you'll start
to
understand it).
5.
IP ADRESSES
=======================================
In
C, there are some functions that will help you manipulating IP addresses. We'll
talk about
inet_addr()
and inet_ntoa() functions.
inet_addr() converts an IP address into an unsigned long. An example:
(...)
dest.sin_addr.s_addr = inet_addr("195.65.36.12");
(...)
/*Remember that this is if you've a struct dest of type sockaddr_in*/
inet_ntoa() converts string IP addresses to long. An example:
(...)
char *IP;
ip=inet_ntoa(dest.sin_addr);
printf("Address is: %s\n",ip);
(...)
Remember
that inet_addr() returns the address in Network Byte Order - so you don't need
to
call
htonl().
6.
IMPORTANT FUNCTIONS
=======================================
In
this section I'll put the function' syntax, the header files you must include
to call it,
and
little comments. Besides the functions mentioned in this document, there are
more, but
I
decided to put only these ones here. Maybe I'll put them in a future version of
this
document
=) To see examples of these functions, you can check the stream client and
stream
server
source code (Sections 8 and 9)
6.1. socket()
=============
#include
#include
int socket(int domain,int type,int protocol);
Let's see the arguments:
domain -> you can set "AF_INET" (set AF_INET to
use ARPA internet protocols)
or "AF_UNIX" if you want to create sockets for
inside comunication.
Those two are the most used, but don't think that there are
just
those. There are more I just don't mention them.
type -> here you put the kind of socket you want
(Stream or Datagram)
If you want Stream Socket the type must be
SOCK_STREAM
If you want Datagram Socket the type must be
SOCK_DGRAM
protocol -> you can just set protocol to 0
socket() gives you a socket descriptor that you can use in later system calls
or
it gives you -1 on error (this is usefull for error checking routines).
6.2. bind()
===========
#include
#include
int bind(int fd, struct sockaddr *my_addr,int addrlen);
Let's see the arguments:
fd
-> is the socket file descriptor returned by socket() call
my_addr -> is a pointer to struct sockaddr
addrlen -> set it to sizeof(struct sockaddr)
bind() is used when you care about your local port (usually when you use
listen() )
and its function is to associate a socket with a port (on your machine). It
returns
-1 on error.
You can put your IP address and your port automatically:
server.sin_port = 0;
/* bind() will choose a random port*/
server.sin_addr.s_addr = INADDR_ANY; /* puts server's IP automatically */
An important aspect about ports and bind() is that all ports bellow 1024 are
reserved.
You can set a port above 1024 and bellow 65535 (unless the ones being
used by other
programs).
6.3. connect()
==============
#include
#include
int connect(int fd, struct sockaddr *serv_addr, int addrlen);
Let's see the arguments:
fd -> is the socket file descriptor returned by
socket() call
serv_addr -> is a pointer to struct sockaddr that contains destination
IP
address and port
addrlen -> set it to sizeof(struct sockaddr)
connect() is used to connect to an IP address on a defined port. It returns -1
on
error.
6.4. listen()
=============
#include
#include
int listen(int fd,int backlog);
Let's see the arguments:
fd -> is the socket file descriptor returned by socket() call
backlog -> is the number of allowed connections
listen() is used if you're waiting for incoming connections, this is, if you
want
someone to connect to your machine. Before calling listen(), you must call
bind()
or you'll be listening on a random port =) After calling listen() you must call
accept() in order to accept incoming connection. Resuming, the sequence of
system calls
is:
1. socket()
2. bind()
3. listen()
4. accept() /* In the next section I'll explain how to use accept() */
As all functions above described, listen() returns -1 on error.
6.5. accept()
=============
#include
int accept(int fd, void *addr, int *addrlen);
Let's see the arguments:
fd -> is the socket file descriptor returned by listen() call
addr -> is a pointer to struct sockaddr_in where you
can determine which host
is calling you from which port
addrlen -> set it to sizeof(struct sockaddr_in) before its address is
passed
to accept()
When someone is trying to connect to your computer, you must use accept() to
get the
connection. It's very simple to understand: you just get a connection if you
accept =)
Next, I'll give you a little example of accept() use because it's a little
different
from other functions.
(...)
sin_size=sizeof(struct sockaddr_in);
if ((fd2 = accept(fd,(struct sockaddr
*)&client,&sin_size))==-1){ /* calls accept() */
printf("accept() error\n");
exit(-1);
}
(...)
From now on, fd2 will be used for add send() and recv() calls.
6.6. send()
===========
int send(int fd,const void *msg,int len,int flags);
Let's see the arguments:
fd -> is the socket descriptor where you want to send data to
msg -> is a pointer to the data you want to send
len -> is the length of the data you want to send (in
bytes)
flags -> set it to 0
This function is used to send data over stream sockets or CONNECTED datagram
sockets.
If you want to send data over UNCONNECTED datagram sockets you must use
sendto().
send() returns the number of bytes sent out and it will return -1 on error.
6.7. recv()
===========
int recv(int fd, void *buf, int len, unsigned int flags);
Let's see the arguments:
fd -> is the socket descriptor to read from
buf -> is the buffer to read the information
into
len -> is the maximum length of the buffer
flags -> set it to 0
As I said above about send(), this function is used to send data over stream
sockets or
CONNECTED datagram sockets. If you want to send data over UNCONNECTED datagram
sockets
you must use recvfrom().
recv() returns the number of bytes read into the buffer and it'll return -1 on
error.
6.8. sendto()
=============
int sendto(int fd,const void *msg, int len, unsigned int flags,
const struct sockaddr *to, int tolen);
Let's see the arguments:
fd -> the same as send()
msg -> the same as send()
len -> the same as send()
flags -> the same as send()
to -> is a pointer to struct
sockaddr
tolen -> set it to sizeof(struct sockaddr)
As you can see, sendto() is just like send(). It has only two more arguments :
"to"
and "tolen" =)
sendto() is used for UNCONNECTED datagram sockets and it returns the number of
bytes
sent out and it will return -1 on error.
6.9. recvfrom()
===============
int recvfrom(int fd,void *buf, int len, unsigned int flags
struct sockaddr *from, int *fromlen);
Let's see the arguments:
fd -> the same as recv()
buf -> the same as recv()
len -> the same as recv()
flags -> the same as recv()
from
-> is a pointer to struct sockaddr
fromlen -> is a pointer to a
local int that should be initialised
to sizeof(struct sockaddr)
recvfrom() returns the number of bytes received and it'll return -1 on error.
6.10. close()
=============
close(fd);
close() is used to close the connection on your socket descriptor. If you call
close(),
it won't be no more writes or reads and if someone tries to read/write will
receive an
error.
6.11. shutdown()
================
int shutdown(int fd, int how);
Let's see the arguments:
fd -> is the socket file
descriptor you want to shutdown
how -> you put one of those numbers:
0 -> receives disallowed
1 -> sends disallowed
2 -> sends and receives disallowed
When how is set to 2, it's the same thing as close().
shutdown() returns 0 on success and -1 on error.
6.12. gethostname()
===================
#include
int gethostname(char *hostname, size_t size);
Let's see the arguments:
hostname -> is a pointer to an array that contains hostname
size -> length of the hostname array (in bytes)
gethostname() is used to get the name of the local machine.
7.
SOME WORDS ABOUT DNS
=======================================
I
created this section, because I think you should know what DNS is. DNS stands
for "Domain
Name
Service" and basically, it's used to get IP addresses. For example, I need
to know the
IP
address of queima.ptlink.net and through DNS I'll get 212.13.37.13 .
This
is important, because functions we saw above (like bind() and connect()) work
with IP
addresses.
To
see you how you can get queima.ptlink.net IP address on c, I made a little
example:
/*
<---- ----="" code="" here="" source="" starts=""> */
#include
#include
/* This is the header file needed for gethostbyname() */
#include
#include
#include
int
main(int argc, char *argv[])
{
struct hostent *he;
if (argc!=2){
printf("Usage: %s \n",argv[0]);
exit(-1);
}
if ((he=gethostbyname(argv[1]))==NULL){
printf("gethostbyname() error\n");
exit(-1);
}
printf("Hostname : %s\n",he->h_name); /* prints the
hostname */
printf("IP Address: %s\n",inet_ntoa(*((struct in_addr
*)he->h_addr))); /* prints IP address */
}
/*
<---- ----="" code="" ends="" here="" source="">
*/
8.
A STREAM SERVER EXAMPLE
=======================================
In
this section, I'll show you a nice example of a stream server. The source code
is all
commented
so that you ain't no possible doubts =)
Let's
start:
/*
<---- ----="" code="" here="" source="" starts=""> */
#include
/* These are the usual
header files */
#include
#include
#include
#define
PORT 3550 /* Port that will be opened */
#define
BACKLOG 2 /* Number of allowed connections */
main()
{
int fd, fd2; /* file descriptors */
struct sockaddr_in server; /* server's address information */
struct sockaddr_in client; /* client's address information */
int sin_size;
if ((fd=socket(AF_INET, SOCK_STREAM, 0)) == -1 ){ /* calls socket() */
printf("socket() error\n");
exit(-1);
}
server.sin_family = AF_INET;
server.sin_port = htons(PORT); /* Remember htons() from
"Conversions" section? =) */
server.sin_addr.s_addr = INADDR_ANY; /* INADDR_ANY puts your IP address
automatically */
bzero(&(server.sin_zero),8); /* zero the rest of the structure */
if(bind(fd,(struct sockaddr*)&server,sizeof(struct sockaddr))==-1){ /*
calls bind() */
printf("bind() error\n");
exit(-1);
}
if(listen(fd,BACKLOG) == -1){ /* calls listen() */
printf("listen() error\n");
exit(-1);
}
while(1){
sin_size=sizeof(struct sockaddr_in);
if ((fd2 = accept(fd,(struct sockaddr
*)&client,&sin_size))==-1){ /* calls accept() */
printf("accept() error\n");
exit(-1);
}
printf("You got a connection from %s\n",inet_ntoa(client.sin_addr) );
/* prints client's IP */
send(fd2,"Welcome to my server.\n",22,0); /* send to the client
welcome message */
close(fd2); /* close fd2 */
}
}
/*
<---- ----="" code="" ends="" here="" source=""> */
9.
A STREAM CLIENT EXAMPLE
=======================================
/*
<---- ----="" code="" here="" source="" starts=""> */
#include
#include
#include
#include
#include
/* netbd.h is needed for struct
hostent =) */
#define
PORT 3550 /* Open Port on
Remote Host */
#define
MAXDATASIZE 100 /* Max number of bytes of data */
int
main(int argc, char *argv[])
{
int fd,
numbytes;
/* files descriptors */
char buf[MAXDATASIZE]; /* buf will store received text */
struct hostent *he; /*
structure that will get information about remote host */
struct sockaddr_in server; /* server's address information */
if (argc !=2) {
/* this is used because our program will need
one argument (IP) */
printf("Usage: %s \n",argv[0]);
exit(-1);
}
if ((he=gethostbyname(argv[1]))==NULL){ /* calls
gethostbyname() */
printf("gethostbyname() error\n");
exit(-1);
}
if ((fd=socket(AF_INET, SOCK_STREAM, 0))==-1){ /* calls socket() */
printf("socket() error\n");
exit(-1);
}
server.sin_family = AF_INET;
server.sin_port = htons(PORT); /* htons() is needed again */
server.sin_addr = *((struct in_addr *)he->h_addr);
/*he->h_addr passes "*he"'s info to "h_addr" */
bzero(&(server.sin_zero),8);
if(connect(fd, (struct sockaddr *)&server,sizeof(struct
sockaddr))==-1){ /* calls connect() */
printf("connect() error\n");
exit(-1);
}
if ((numbytes=recv(fd,buf,MAXDATASIZE,0)) == -1){ /* calls recv() */
printf("recv() error\n");
exit(-1);
}
buf[numbytes]='\0';
printf("Server Message: %s\n",buf); /* it prints server's welcome
message =) */
close(fd); /* close fd =) */
}
/*
<---- ----="" code="" ends="" here="" source=""> */
10.
LAST WORDS
=======================================
As
I'm just a simple human, it's almost certain that there are some errors on this
document.
When
I say errors I mean English errors (because my language is not the English) but
also
technical
errors. Please email me if you detect any error =)
But
you must understand that this is the first version of this document, so , it's
natural not
to
be very complete (as matter of fact I think it is ) and it's also very natural
to have
stupid
errors. However, I can be sure that source code presented in this document
works fine.
If
you need help concerning this subject you can email me at
SPECIAL
THANKS TO: Ghost_Rider (my good old mate), Raven (for letting me write this
tutorial)
and all my friends =)
11.
COPYRIGHT
=======================================
All
copyrights are reserved. You can distribute this tutorial freely, as long you
don't change
any
name or URL. You can't change a line or two, or add another lines, and then
claim that this
tutorial
is yours. If you want to change something, please email me at .
BASIC
C Socket Programming In Unix For Newbies
<==================================>
Written
by: BracaMan
E-mail
: BracaMan@clix.pt
ICQ
: 41476410
URL
: http://www.BracaMan.net
For
more tutorials: http://code.box.sk
http://blacksun.box.sk
Hello, my name is Jack Sparrow. I'm a 50 year old self-employed Pirate from the Caribbean.
